Quick Details

  • Condition: New
  • Type: Screw
  • Configuration: Stationary
  • Power Source: AC Power
  • Lubrication Style: Lubricated
  • Mute: Yes
  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: ELANG
  • Model Number: ERC-60SA
  • Voltage: 380v/3ph/50hz(or Customized)
  • Dimension(L*W*H): 1300*1000*1470mm
  • Weight: 1150kg
  • Certification: ISO9001/CE/TUV/UL/SGS/ASME
  • Warranty: One Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: Super September 60Hp 45Kw Rotary Screw Air Compressor For Plastics
  • Driven Method: Belt driven
  • Belt: Germany Optibelt
  • Cooling method: Air cooling/Water cooling
  • Application: Packing Industrial Air Compressor
  • Compressed medium: Air
  • Working pressure: 0.75/0.8/1/1.25MPA
  • Motor power: 45kw 60HP
  • Compression stage: 1
  • capacity: 8m3/min(282.5cfm)

Packaging & Delivery

Packaging Details Export standard plywooden package for Super September 60Hp 45Kw Rotary Screw Air Compressor For Plastics
Delivery Time 7-15 days after receive the payment

Product Description

Super September 60Hp 45Kw Rotary Screw Air Compressor For Plastics

Belt driven, which allows the speed of the rotor to be changed by different diameter pulleys.
1. The belt tension for each operating condition is optimized
2. By avoiding excessive start-up tension, greatly extending the belt working life.
3. Always ensure the correct pulley connection
4. Replace the belt is very easy and fast, and do not need to adjust the original settings.
5. The whole belt driven system safe and trouble-free operation.



          Technical Data:

 ModelERC-60SA

 Working

 Pressure

psig100116145181
bar781012.5
 Air Deliverycfm282.5271.9243.6211.9
m3/min87.76.96
 Motor Powerkw/hp45/60

 Motor Efficiency

 Class

 Ultraefficient/IE3/IP54/IP55
 Type of Driving Belt Driven
 Type of Cooling Air Cooling/Water cooling
 Dimension(mm)

L

1300
W1000
H1470
 Weight kg1150

 Output pipe

 Diameter

 11/2“
 Certification CE/ISO9001:2015/TUV/UL/SGS/ASME
 Voltage

380V/3PH/50HZ/60HZ

220V/3PH/50HZ/60HZ

440V/3PH/50HZ/60HZ

415V/3PH/50HZ/60HZ  double voltage is also ok

 Exhaust oil volum



<3ppm

 Noise dbtest according the national standard GB/T4980-2003
 outlet air humidityambient temperature+15℃
 Cooling air volumem3/min185
Cooling water volumeL/min30



A.Control Panel

Intelligent microcomputer-based control technology can monitor and control in all aspects the    complete machine following your instructions.Remote control realizes unattended operation.

B.Oil filter

Rotary filters are applied to completely remove the impurities in the lubricating oil,easy to replace and free of oil impregnate.

C.Cooler

It is designed for low temperature difference to increase heat exchang area,and ideal to be applied to high-temperature and high-humidity operating environment.

D.Motor

First-class motors are adopted,with the level of protection being lp54 and insulation level being F.

E.Acoustic enclosure

It is designed into fully-closed mute box,in which soundabsorbing sponge are attached for effective absorption of noise,thereby making the noise 3-5dB(A)lower than that made by the compressors of the same kind. It is reasonably structured overall and very easy to maintain and repair.



After Sales

ELANG Company with Germany Standard and 10 years exporting experience help us won more than 50
loyal foreign agents, worldwide agents guarantee installation, after service maintenance available in time,
our sales department 24hours on-line service, also welltrained engineers available to overseas service.
So whenever you have any question about air compressor, please don’t hesitate to contact us.
Other Products
Company Profile

ELANG group is located in Nanxiang Industrial Development Zone, Jiading District, Shanghai, which is

the hightech enterprises in Shanghai and China's quality service integrity AAAclass corporation. As one

of the world's largest air compressor system suppliers, ELANG currently develops all the Rotary Screw

Air Compressors.

German standard, Made in ELANG. As the industry's leading technology enterprise, ELANG has always

being focused on the talent cultivation and quality pursuit. We have a good batch of talent team with solid

foundation of air dynamics and always active in mechanical application and technology R&D, that make

ELANG achieved unparalleled advantages in the technology R&D and product innovation and

customized etc.

Behind such a huge system, it is ELANG people constant persist.  Choose ELANG, without worry for

fifty years. ELANG give 10 years quality guaranty concept for its sold products, 24-hour after-sales

service, full-way after-salestracking and lifelong maintenance.



Certificate

FAQ

1.Why customer choose us?
   ELANG INDUSTRIAL (SHANGHAI) CO., LTD., with 18 years old history,we are specialized in

   Rotary Screw Air Compressor.

   Germany Standard and 10 years exporting experience help us won more than 50 loyal foreign

   agents. We warmly welcome your small trial order for quality or market test.
2.Are you a manufacturer or trading company?
   We are professional manufacturer with big modern factory in Shanghai,China.
   Both OEM & ODM service can be accepted.
3.What’s your delivery time?
   Generally 3 to 7 days, if urgently order, pls contact our sales in advance.
4.How long is your air compressor warranty?
   One year for the whole machine and two years for screw air end, except consumable spare

   parts.
5.How long could your air compressor be used?
   Generally, more than 10 years.
6. What's payment term?
   T/T, L/C,  D/P,  Western Union, Paypal, Credit Card, and etc.

   Also we could accept USD, RMB, Euro and other currency.
7.How about your customer service?
   24 hours on-line service available. 48hours problem solved promise.
8.How about your after-sales service?

   1. Provide customers with installation and commissioning online instructions.

   2. Well-trained engineers available to overseas service.

   3. Worldwide agents and after service available.
